Release Tool For TE DUAC Pins & Sockets

Accessory connection plugs are used to connect accessories to the two-conductor plugs on the radio box terminal strip in positions 8, 9 and 10, referred in the BMW instructions as Accessory I, II or III. Three (3) two conductor socket housings along with six sockets are provided with each PN quantity selected. Formerly BMW PN 71 60 2 452 846

BMW 2.5 mm high current plug to connect radios and other devices to the radio power plug on your BMW motor. BMW plug Code A (black housing) supplied with two sockets for 14 - 18 AWG wire connections (w/conductor & insulation crimps). Formerly BMW PN 71 60 2 452 887

The radar connection plug is used to connect accessories (including moving radar) to the four-conductor plug on the radio box terminal strip in position 11, referred in the BMW instructions as Radar Connection on the K52 / 2015 - 2022 R 1200 / 1250 RT-P models. One four-conductor socket housing along with four sockets are provided with each PN quantity selected. Formerly BMW PN 71 60 2 452 849

The radio speaker plug is used to connect radio speaker outputs to the six-conductor plug on the radio box terminal strip in position 12, referred in the BMW instructions as Fairing Speakers. One six conductor socket housings along with six sockets are provided with each PN quantity selected. Formerly BMW PN 71 60 2 452 844
